Ultrasonic Bath (Sonicator) with Heater

Make : ANALAB | HSN Code : 84562000

Supplied with Lid, Basket, Power Cord, Operational & Instruction Manual with SOP, Calibration Test Certificate (Without Traceability Document) and Warranty Card.

Technical Specification

• Controller : Microcontroller Based
• Technology : Latest IGBT Based
• Display : 6 digit Large LED Display for time & temperature
• Timer : 99 minutes and 59 seconds
• Transducers : PZT sandwich type, bonded at the base of SS tank.
• Transducer Frequency : 33 ± 3 KHz (40 KHz will be available optionally)
• Frequency Display : Yes
• Temperature Range : 5ºC above ambient to 80ºC
• Type of Heater : Silicon / Cartridge
• Heater Power : Upto 1000 watts
• Auto Degassing : Yes, user adjustable time
• Unit & Tank MOC : Stainless Steel
• Drain Valve : ½” Ball Valve will be provided to clean the tank. (6.5 Liters & Above)
• Power Supply : 230VAC ± 10%, 50Hz



Sr. No.	Model	Tank Capacity	Tank Size (L X W X H)	Basket Size (L X W X H)	Ultrasonic Power
01	AU33-2.5	2.5 Liters	228 X 140 X 100 mm (9" X 5.5" X 4")	200 X 100 X 60 mm	60 Watts
	AU40-2.5
02	AU33-3.5	3.5 Liters	300 X 150 X 100 mm (12" X 6" X 4")	250 X 100 X 60 mm	120 Watts
	AU40-3.5
03	AU33-6.5	6.5 Liters	300 X 150 X 150 mm (12" X 6" X 6")	270 X 100 X 100 mm	180 Watts
	AU40-6.5
04	AU33-10	10.0 Liters	300 X 228 X 150 mm (12" X 9" X 6")	270 X 190 X 100 mm	240 Watts
	AU40-10
05	AU33-15	15.0 Liters	400 X 250 X 150 mm (16” x 10” x 6”)	350 X 200 X 100 mm	360 Watts
	AU40-15
06	AU33-20	20.0 Liters	455 X 300 X 150 mm (18" X 12" X 6")	420 X 270 X 100 mm	480 Watts
	AU40-20
07	AU33-25	25.0 Liters	500 X 250 X 200 mm (20” X 10” X 8”)	450 X 200 X 150 mm	600 Watts
	AU40-25
08	AU33-30	30.0 Liters	500 X 300 X 200 mm (20" X 12" X 8")	450 X 250 X 150 mm	720 Watts
	AU40-30
09	AU33-42	42.0 Liters	760 X 320 X 175 mm (30” X 13” X 7”)	710 X 250 X 150 mm	780 Watts
	AU40-42



Note:-

• Technical specification like Size of Tank, Ultrasonic Power etc. may change without notice for purpose of continuous upgradation in instruments.

• Price for customized size will be available on request.
